Product Details
Place of Origin: China
Brand Name: HETECH
Certification: ISO9001,ISO14001,ISO13485,IATF16949
Model Number: HC090TG35050-D80V.1
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Delivery Time: 4-6weeks
Payment Terms: T/T
Supply Ability: 50K/month
P/N: |
HC090TG35050-D80V.1 |
Size: |
9"(TN) |
Display Type: |
(TN) |
Resolution: |
800*480 |
Outline Dimension: |
211.1(W )*126.5(H)*5(T)mm |
Active Area: |
198(W)*111.696(H)mm |
Brightness: |
350cd/㎡ |
Interface: |
50pinRGB |
Viewing Angle: |
70/70/50/70 |
Operation Temp.: |
-20~70℃ |
Storage Temp.: |
-30~80℃ |
Contrast Ratio: |
500 |
Aspect Rati16:9o: |
16:9 |
Application: |
Fish Feed System, Halogen Moisture Analyzer |
P/N: |
HC090TG35050-D80V.1 |
Size: |
9"(TN) |
Display Type: |
(TN) |
Resolution: |
800*480 |
Outline Dimension: |
211.1(W )*126.5(H)*5(T)mm |
Active Area: |
198(W)*111.696(H)mm |
Brightness: |
350cd/㎡ |
Interface: |
50pinRGB |
Viewing Angle: |
70/70/50/70 |
Operation Temp.: |
-20~70℃ |
Storage Temp.: |
-30~80℃ |
Contrast Ratio: |
500 |
Aspect Rati16:9o: |
16:9 |
Application: |
Fish Feed System, Halogen Moisture Analyzer |
9 Inch TFT LCD Display with resistive touch panel and wide temperature range
Product Description:
HC090TG35050-D80V.1 built-in TN panel is a cost-effective 9-inch TFT LCD screen that offers a number of important features, making it an ideal choice for users looking for a high-performance display. This display with an outline dimension of 211.10mm*126.50mm*6.50mm is equipped with a backlight component that can generate 300 nits luminance, making it easy for users to read indoors. And it includes a resistive touch screen that is capable of withstanding scratches, impacts, and even harsh environments. With a resolution of 800*480 pixels and a contrast ratio of 500:1, this display with a 50pin RGB interface can show high-quality color representation. In terms of operation temperature, this display is designed to operate in environments of -20℃ to 70℃. Combining these advantages, the HC090TG35050-D80V.1 is suited to using in fish feed system, halogen moisture analyzer and other applications.
General Specification:
| P/N | HC090TG35050-D80V.1 |
| Size | 9inch |
| Display type |
Normally White, Transmissive
|
| Resolution | 800*480 |
| Outline Dimension(mm) | 211.1(W )*126.5(H)*5(T)mm |
| Active Area(mm) | 198(W)*111.696(H)mm |
| Brightness(cd/m²) | 350 |
| Viewing Angle(L/R/T/B) | 70/70/50/70 |
| Interface | 50pinRGB |
| Operation Temperature | -20~70℃ |
| Storge Temperature | -30~80℃ |
| Aspect ratio | 16:9 |
| Contrast ratio | 500 |
| Application | Fish feed system, halogen moisture analyzer |
Pin assignment:
Backlight Driving Conditions:
| Item | Symbol | MIN | TYP | MAX | UNIT |
|
Voltage for LED backlight
|
Vf | 8.5 | 9.3 | 10.5 | V |
|
Current for LED backlight
|
If | 160 | 180 | - | mA |
|
LED life time
|
- | 20000 | - | - | hrs |
Product drawings:
9-inch lcd display series:
|
9-inch LCD Display Sizes
|
|||||||||||
| Warm reminds:if models listed below can't meet your requirements,customization can be made according to your specific requirements but it is not limited to LCM,RTP,CTP,driver board.etc. | |||||||||||
| No. | Size | Part No. | LCD type | Resolution | Outline dimension | Active area | Interface | Contrast ratio | Brightness | Operation temperature | Storage temperature |
| 1 | 9" | HC090IK50057-C16 | IPS | 1024*600 | 211.10*126.50*5.7mm | 196.61*114.15mm | 40pinLVDS | 800 | 500 | -20~70℃ | -30~80℃ |
| 2 | 9" | HC090TG25050-D80 | TN | 800*480 | 211.10*126.50*5.00mm | 198.00*111.7mm | 50pinRGB | 500 | 250 | -20~70℃ | -30~80℃ |
| 3 | 9" | HC090TG35050-D80V.1 | TN | 800*480 | 211.10*126.50*6.50mm | 198.00*111.7mm | 50pinRGB | 500 | 300 | -20~70℃ | -30~80℃ |
| 4 | 9" | HC090TGA0057-97 | TN | 800*480 | 211.10*126.50*5.7mm | 198.00*111.69mm | 50pinRGB | 500 | 1000 | -20~70℃ | -30~80℃ |
| 5 | 9" | HC090IK50057-C16V.C | IPS | 1024*600 | 211.10*126.50*7.10mm | 196.60*114.15mm | 40pinLVDS | 800 | 500 | -20~70℃ | -30~80℃ |
| 6 | 9" | HC090IKA0057-C16H | IPS | 1024*600 | 211.10*126.50*5.70mm | 196.60*114.15mm | 40pinLVDS | 800 | 1000 | -20~70℃ | -30~80℃ |
| 7 | 9" | HC090TG35050-D80 | TN | 800*480 | 211.10*126.50*5.00mm | 198.00*111.7mm | 50pinRGB | 500 | 350 | -20~70℃ | -30~80℃ |
| 8 | 9" | HC090TG55050-D80 | TN | 800*480 | 211.10*126.50*5.00mm | 198.00*111.7mm | 50pinRGB | 500 | 550 | -20~70℃ | -30~80℃ |
Customization:
FAQ:
Q1. Can I have a sample order for LCD Display
A: Yes, we welcome sample order to test and check quality
Q2. What about the lead time?
A: Usually 4~5 days for sample orders if goods are in stock, and 4~6 weeks for mass production (basing on the quantity and product).
Q3. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx.
Q4. How to proceed an order for LCD Display?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q6: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
B.Besides danmage caused by human factors, within one year warranty from the start of shipping.
If there are special conditions, the warranty time will be separately notified.
